型號/ Model:

LC-MB40-01

技術參數/Technologic Data

認證Certificate

CE

引用標準based on:

EN60598

輸  入/Input

額定電壓/Rated voltage:

AC85～265V

工作頻率/Frequency:

50～60Hz

輸入功率(負載)/Input power(Loading):

40W

輸  出/Output

輸出電流(負載)/Output current (Loading):

DC 700mA

輸出電壓(負載)/Output voltage (loading):

DC 40-60V

輸出電壓(空載)/Output voltage(no loading)

DC＜60V

絕緣強度/Voltage resistance

輸入—輸出/Input-Output

AC 1.5KV/5mA 1Min

輸入—燈殼/Input-Housing

AC 1.5KV/5mA 1Min

非性能/Non- function

外觀/External appearance

1.表面無污跡，劃痕，環氧，變形/The surface has no dirty vestige, rowing the , the wreath oxygen, transform       2.電源線和標簽紙對應 /Power cable and the label paper to should                 3.日期印清晰/The date print clear

標示/Mark

產品標簽正確清晰，平整，無折痕/The product label is right clear, neat, have no folding line

其它/Other

說明書和其它相關資料是否齊全/Whether manual and other related data are well-found or not

防護等級/Protection grade

IP20

工作溫度/Working Temperature

-25℃～+40℃
